~NMS with Nagios 3.0~ on CentOS 5.2! -pt1

Tuesday, October 13, 2009

Part 1-Installation.
Okay, here i post a tutorial on how to install this. software requirement are as follows : -CentOS 5.2 (linux base operating system)
-stable internet connection to install nagios & centOS plug-ins.

How to install CentOS 5.2?
-go to this url: http://www.howtoforge.com/perfect-server-centos-5.2-ispconfig-3
(i prefer to boot dual OS [wixdows xp+linux] - put your linux onthe other partition).
-burn iso image into a dvd n bootform dvd. iso image are available here [url]: http://isoredirect.centos.org/centos/5/isos/i386/


Installation of Nagios 3.0

Installyumplug-ins & yumex. Install some recommended packages to prevent problems with packages (broken/3rd party) and kernel-modules (root privileges needed):

type this to become root admin then type this command to install yum plug-in:

su -l

yum install yumex yum-fastestmirror yum-skip-broken yum-kmod yum-kernel-module yum-priorities.


RPMforge

The RPMforge-repository provides many packages like multimedia applications and drivers. Install the repository:

rpm -ivh http://apt.sw.be/redhat/el5/en/i386/RPMS.dag/rpmforge-release-0.3.6-1.el5.rf.i386.rpm

wget -c http://dag.wieers.com/rpm/packages/rpmforge-release/rpmforge-release-0.3.6-1.el5.rf.i386.rpm

rpm -Uvh oscc-repos2-0.0.1-1.noarch.rpm

Nagios installation command

These are the command that need to be execute at the linux terminal and need to be compile to setting up the system from start. Execution is a must or the system will not appear in the web browser.

echo “***** Starting Nagios Quick-Install: ” `date`

echo “***** Installing pre-requisites”

echo “***** Installing WGET so we could download the packages that we need”

yum -y install wget

echo “***** WGET has been installed”

# Installing Packages For Centos echo “***** Installing very Important packages otherwise out Nagios wont work”

yum -y install make make autoconf httpd php-snmp.i386 php-pear.noarch php-pear-File.noarch php-rrdtool.i386 php-xml.i386 php-mcrypt.i386 php-mysql.i386 php-ncurses.i386 php-devel.i386 php-gd.i386 php-jpgraph.noarch php-common

yum -y install gcc g++ flex byacc

yum -y install glibc glibc-common

yum -y install gd gd-devel

yum -y install perl

# Adding user nagios

echo “***** Setting up the environment”

useradd -m nagios echo “YOUR_DESIRED_PASSWORD”

passwd --stdin nagios groupadd nagcmd

usermod -a -G nagcmd nagios

usermod -a -G nagcmd apache

# Getting Nagios Source Tarball with Plugins

echo “***** Getting the Nagios Source and Plug-Ins”

cd /usr/local/src

wget http://osdn.dl.sourceforge.net/sourceforge/nagios/nagios-3.0.6.tar.gz

wget http://osdn.dl.sourceforge.net/sourceforge/nagiosplug/nagios-plugins-1.4.13.tar.gz

tar xzf nagios-3.0.6.tar.gz

tar xzf nagios-plugins-1.4.13.tar.gz

# Compiling and Nagios Installation echo “***** Installing Nagios”

cd /usr/local/src/nagios-3.0.6

./configure --with-command-group=nagcmd

make all

make install

make install-init

make install-config

make install-commandmode

make install-webconf

# Setting up Password for Web authentification

echo “***** Setting up htpasswd auth”

htpasswd -nb nagiosadmin yourpassword > /usr/local/nagios/etc/htpasswd.users

service httpd restart

# Installing Nagios Plugins if fail do make clean

echo “***** Setting up Nagios Plug-Ins”

cd /usr/local/src/nagios-plugins-1.4.13

./configure --with-nagios-user=nagios --with-nagios-group=nagios

make

make install

# Seting up SELinux

echo “***** Fixing SELinux”

chcon -R -t httpd_sys_content_t /usr/local/nagios/sbin/

chcon -R -t httpd_sys_content_t /usr/local/nagios/share/

echo “***** Starting Nagios”

This command should be apply every times after your computer has been reboot or the system could not be opened.

chkconfig --add nagios

chkconfig nagios on

service nagios start

service iptables stop

Nagios web browser:

Open this url to view your system. You will see this interface on the first page you open.

http://localhost/nagios

u should see the page up there.


then do the configuration on the hosts.cfg file to monitor your switch/router/server and etc. After some configuration, u could do this and view this.











Thats all for now.
to be continued in part 2.
the configuration part.

++ coming SOON ++
